Specifications
|
|
| Interface |
| WAN Port |
WAN1: 1000Base-TX, RJ-45 or 100/1000M SFP Slot (model Fn) |
| WAN2: 1000Base-TX, RJ-45 |
| LAN Port |
5x 10/100/1000Base-TX LAN, RJ-45 |
| USB Port |
2x USB 2.0 for 3G/4G/LTE USB modem, storage, printer or thermometer |
| RJ-11 Port for Voice |
2x FXS + 1x Life Line (Vn-plus, Vac model) |
| 2.4G WLAN |
802.11b/g/n (n/n-plus/ac/Vac model) |
| 5G WLAN |
300Mbps 802.11a/n (n-plus/ac/Vac model) |
| 867Mbps 802.11ac (ac/Vac model |
| Performance |
| NAT Throughput |
450 Mbps |
| NAT Throughput w/ Hardware Acceleration |
900 Mbps |
| IPsec VPN Performance |
75 Mbps (AES 256 bits) |
| SSL VPN Performance |
35 Mbps |
| Max. Number of NAT Sessions |
50,000 |
| Max. Concurrent VPN Tunnels |
50 |
| Max. Concurrent SSL VPN |
25 |
| Internet Connection |
| IPv4 |
PPPoE, DHCP, Static IP, PPTP/L2TP |
| IPv6 |
PPP, DHCPv6, Static IP, TSPC, AICCU, 6rd, 6in4 Static Tunnel |
| Multi-VLAN/PVC |
yes |
| Wireless WAN |
yes (n/n-plus/Vn-plus/ac/Vac model) |
| 3G/4G/LTE WAN with USB modem |
yes |
| Load Balancing |
IP-based, Session-based |
| WAN Active on Demand |
Link Failure, Traffic Threshold |
| Connection Detection |
ARP, Ping |
| WAN Data Budget |
yes |
| Dynamic DNS |
yes |
| DrayDDNS |
yes |
| LAN Management |
| VLAN |
802.1q Tag-based, Port-based |
| Max. Number of VLAN |
8 |
| DHCP Server |
Multiple IP Subnet, Custom DHCP Options, Bind-IP-to-MAC |
| LAN IP Alias |
yes |
| Wired 802.1x Authentication |
yes |
| Port Mirroring |
yes |
| Local DNS Server |
yes |
| Conditional DNS Forwarding |
yes |
| Hotspot Web Portal |
yes |
| Hotspot Authentication |
Click-Through, Social Login, SMS PIN |
| Networking |
| Routing |
IPv4 Static Routing, IPv6 Static Routing, Inter-VLAN Routing, RIP, BGP, Policy-based Routing |
| High Availability |
yes |
| DNS Security (DNSSEC) |
yes |
| Local RADIUS server |
yes |
| SMB File Sharing |
yes (Requires external storage) |
| Multicast |
IGMP Proxy, IGMP Snooping & Fast Leave, Bonjour |
| VPN |
| LAN-to-LAN |
yes |
| Teleworker-to-LAN |
yes |
| Protocols |
PPTP, L2TP, IPsec, L2TP over IPsec, SSL, GRE, IKEv2, IKEv2-EAP |
| User Authentication |
Local, RADIUS, LDAP, TACACS+, mOTP |
| IKE Authentication |
Pre-Shared Key, X.509 |
| IPsec Authentication |
SHA1, MD5 |
| VPN Redundancy |
Load Balancing, Failover |
| Single-Armed VPN |
yes |
| NAT-Traversal (NAT-T) |
yes |
| Firewall & Content Filtering |
| NAT |
Port Redirection, Open Ports, Port Triggering, DMZ Host, UPnP |
| ALG (Application Layer Gateway) |
SIP, RTSP, FTP, H.323 |
| VPN Pass-Through |
PPTP, L2TP, IPsec |
| IP-based Firewall Policy |
yes |
| Content Filtering |
Application, URL, DNS Keyword, Web Features, Web Category* (*: subscription required) |
| DoS Attack Defense |
yes |
| Bandwidth Management |
| IP-based Bandwidth Limit |
yes |
| IP-based Session Limit |
yes |
| QoS (Quality of Service) |
TOS, DSCP, 802.1p, IP Address, Port, Application |
| VoIP Prioritization |
yes |
| Wireless LAN (n/n-plus/Vn-plus/ac/Vac model) |
| Number of SSID |
4 per radio band |
| Security |
WEP, WPA, WPA2, WPS |
| Authentication |
Pre-Shared Key, 802.1x |
| AirTime Fairness |
yes |
| Band Steering |
yes (n-plus/Vn-plus/ac/Vac model) |
| WMM |
yes |
| WDS |
Bridge, Repeater |
| Access Control |
Access List, Client Isolation, Hide SSID, Wi-Fi Scheduling |
| VoIP Gateway (Vn-plus/Vac model) |
| Protocol |
SIP, RTP/RTCP, ZRTP |
| SIP Registrars |
12 |
| Dial Plan |
Phone Book, Digit Map, Call Barring, Regional |
| Call Features |
Call Waiting, Call Transfer, Scheduled DND, Hotline |
| Voice Codec |
G.711 A/u law, G.723.1, G.726, G.729 A/B |
| Caller ID |
FSK_ETSI, FSK_BELLCORE, DTMF |
| Management |
| Local Service |
HTTP, HTTPS, Telnet, SSH, TR-069 |
| Config File Export & Import |
yes |
| Config File Compatibility |
Vigor2920 |
| Firmware Upgrade |
TFTP, HTTP, TR-069 |
| 2-Level Administration Privilege |
yes |
| Access Control |
Access List, Brute Force Protection |
| Notification Alert |
SMS, E-mail |
| SNMP |
v2, v2c, v3 |
| Syslog |
yes |
| Managed by VigorACS |
yes |
| Central AP Management |
20 VigorAP |
| Central Switch Management |
10 VigorSwitch |
| Physical |
| Power Supply |
DC 12V @ 1.5-2A |
| Dimension |
241mm x 166mm x 46mm |
| Operating Temperature |
0 to 45°C |
| Storage Temperature |
-25 to 70°C |
| Operating Humidity (non-condensing) |
10 to 90% |
