| Category |
Specifications |
| Radios |
- 2.4 GHz 802.11b/g/n/ax client access radio
- 5 GHz 802.11a/n/ac/ax client access radio
- 2.4 GHz & 5 GHz dual-band WIDS/WIPS, spectrum analysis, & location analytics radio
- 2.4 GHz Bluetooth Low Energy (BLE) radio with Beacon and BLE scanning support
- Concurrent operation of all four radios
- Supported frequency bands (country-specific restrictions apply):
- 2.401 – 2.484 GHz
- 5.150 – 5.250 GHz (UNII-1)
- 5.250 – 5.350 GHZ (UNII-2)
- 5.490 – 5.730 GHz (UNII-2C)
- 5.735 – 5.825 GHz (UNII-3)
|
| Antenna |
- Internal Antenna (5.4 dBi gain at 2.4 GHz, 6 dBi gain at 5 GHz)
|
| 802.11ax, 802.11ac Wave 2 and 802.11n Capabilities |
- DL-OFDMA**, UL-OFDMA**, TWT support**, BSS Coloring**
- 2 x 2 multiple input, multiple output (MIMO) with two spatial streams
- SU-MIMO, UL MU-MIMO** and DL MU-MIMO support
- Maximal ratio combining (MRC) & beamforming
- 20 and 40 MHz channels (802.11n, 40Mhz on 5Ghz only); 20, 40, and 80 MHz channels (802.11ac Wave 2); 20, 40 and 80 MHz channels (802.11ax)
- Up to 1024-QAM on both 2.4 GHz & 5 GHz bands
- Packet aggregation
|
| Power |
- Power over Ethernet: 37 – 57 V (802.3at compatible)
- Power consumption: 30W max (802.3at). Note: actual power consumption may vary depending on the AP usage.
- Power over Ethernet injector sold separately
Note: Actual power consumption may vary depending on the AP usage.
|
| Interfaces |
- 1x 10/100/1000 BASE-T Ethernet (RJ45) (Uplink on the back)
- 1x 10/100/1000 BASE-T Ethernet (RJ45) with 802.3af Power over Ethernet output
- 2x 10/100/1000 BASE-T Ethernet (RJ45) outputs
- 1x Passthrough port (non-managed).
|
| Mounting |
- All standard mounting hard wares, including MA-MNT-MR-H1A, Wall Mount Kit for MR30H/36H
- Desktop, ceiling, and wall mount capable
- Ceiling tile rail (9/16, 15/16 or 1 1⁄2” flush or recessed rails), assorted cable junction boxes
- Bubble level on mounting cradle for accurate horizontal wall mounting
|
| Physical Security |
- Two security screw options (included) (10 mm long and 2.5 mm diameter and 4.7 mm head)
- Kensington lock hard point
|
| Environment |
- Operating temperature: 32 °F to 104 °F (0 °C to 40 °C)
- Humidity: 5 to 95% non-condensing
- Operating altitude: Up to 40,000 feet (12,192 meters)
|
| Reliability |
- Mean Time Between Failure (MTBF): 257,215hrs at +25°C operating temperature
|
| Physical Dimensions |
- 15.5 cm x 11 cm x 2.3 cm (6.1″ x 4.33″x 0.9″) not including desk mount feet or mount plate
- Weight: 17.35 oz (492 g)
|
| Security |
- Integrated Layer 7 firewall with mobile device policy management
- Real-time WIDS/WIPS with alerting and automatic rogue AP containment with Air Marshal
- Flexible guest access with device isolation
- VLAN tagging (802.1q) and tunneling with IPsec VPN
- PCI compliance reporting
- WEP***, WPA, WPA2-PSK, WPA2-Enterprise with 802.1X, WPA3 – Personal, WPA3 – Enterprise, WPA3 – Enhanced Open (OWE)**
- EAP-TLS, EAP-TTLS, EAP-MSCHAPv2, EAP-SIM
- TKIP and AES encryption
- Enterprise Mobility Management (EMM) & Mobile Device Management (MDM) integration
- Cisco ISE integration for Guest access and BYOD Posturing
|
| Quality of Service |
- Advanced Power Save (U-APSD)
- WMM Access Categories with DSCP and 802.1p support
- Layer 7 application traffic identification and shaping
|
| Mobility |
- PMK, OKC, & 802.11r for fast Layer 2 roaming
- Distributed or centralized layer 3 roaming
|
| Analytics |
- Embedded location analytics reporting and device tracking
- Global L7 traffic analytics reporting per network, per device, & per application
|
| LED Indicators |
- 1 power/booting/firmware upgrade status
|
| Regulatory |
- RoHS
- For additional country-specific regulatory information, please contact Meraki sales
|
| Warranty |
- Lifetime hardware warranty with advanced replacement included
|
| Ordering Information |
|
