Cisco Meraki wifi router CW9164

  • 2×2:2 and 4×4:4 MU-MIMO 802.11ax compatible
  • 7.49 Gbps tri-radio aggregate frame rate
  • 24×7 real-time WIDS/WIPS and spectrum analytics via dedicated fourth radio
  • Integrated Bluetooth Low Energy Beacon and scanning radio
  • 1x 2.5 Gbps mGig Ethernet port
  • USB 2.0 host interface (Type A connector) with a 4.5W power budget
  • Enhanced transmit power and receive sensitivity
  • Full-time Wi-Fi location tracking via dedicated 3rd radio
  • Integrated enterprise security and guest access
  • Application-aware traffic shaping
  • Optimized for voice and video
  • Self-configuring, plug-and-play deployment
  • Sleek design blends into office environments

Categories: , Tags: , , , , , , , , , ,

THÔNG SỐ KỸ THUẬT:

Category Specifications
Radios

  • 2.4 GHz 802.11b/g/n/ax client access radio

  • 5 GHz 802.11a/n/ac/ax client access radio

  • 6 GHz 802.11ax client access radio

  • 2.4 GHz, 5 GHz, and 6 GHz tri-band Air Marshal WIDS/WIPS, spectrum analysis, & location analytics radio

  • 2.4 GHz Bluetooth Low Energy (BLE) radio with Beacon and BLE scanning support Concurrent operation of all five radios

Supported frequency bands (country-specific restrictions apply): :

  • 2.401 – 2.484 GHz ISM
  • 5.150 – 5.250 GHz (UNII-1)
  • 5.250 – 5.350 GHZ (UNII-2A)
  • 5.490 – 5.730 GHz (UNII-2C)
  • 5.735 – 5.825 GHz (UNII-3)
  • 5.850 – 5.895 GHz (UNII-4)
  • 5.925 – 6.425 GHz (UNII-5)
  • 6.425 – 6.525 GHz (UNII-6)
  • 6.525 – 6.875 GHz (UNII-7)
  • 6.875 – 7.125 GHz (UNII-8)
Antenna

  • Integrated omni-directional antennas

    • 2.4 GHz: Peak gain 3.2 dBi, internal antenna, omnidirectional in azimuth

    • 5 GHz: Peak gain 4.7 dBi, internal antenna, omnidirectional in azimuth

    • 6 GHz: Peak gain 4.5 dBi, internal antenna, omnidirectional in azimuth
802.11 ax compatible, 802.11ac Wave 2 and 802.11n Capabilities

  • UL/DL-OFDMA

  • Target Wait Time (TWT)

  • BSS coloring*

  • SU-MIMO and DL MU-MIMO support

  • Maximal ratio combining (MRC)

  • 802.11ax beamforming

  • 20 and 40 MHz channels (802.11n)

  • 20, 40, 80 MHz channels (802.11ac Wave 2)

  • 20, 40, 80 and 160MHz channels (802.11ax)

  • Up to 1024-QAM on 2.4 GHz, 5 GHz and 6 GHz bands

  • Packet aggregation – A-MPDU (transmit and receive), A-MSDU (transmit and receive)
Power

  • Power over Ethernet: 37 – 42.5 V (802.3at compliant)

  • DC Power Adapter (12V)

  • Power consumption: 30W

  • Minimum power requirement: 30W (802.3at complaint)

  • Power over Ethernet injector and DC adapter sold separately

Actual power consumption may vary depending on the AP usage
Interfaces

  • 1x 100/1000/2.5G BASE-T Ethernet (RJ45)

  • 1x DC power connector (5.5 mm, center positive)

  • USB 2.0 at 4.5W (with 802.3at power)

  • Console – Only available in DNA Mode
Mounting

  • All Cisco standard mounting hardware supported (AIR-AP-BRACKET-2 included)

  • Desktop, ceiling, and wall mount capable

  • Ceiling tile rail (9/16, 15/16, or 1 ½” flush or recessed rails), assorted cable junction boxes
Physical security

  • Two security screw options (included) (13.5 mm long and 2.5 mm diameter and 5 mm head)

  • Kensington lock
Environment

  • Nonoperating (storage) temperature: -22° to 158°F (-30° to 70°C)

  • Nonoperating (storage) altitude test: 25˚C (77°F) at 15,000 ft (4600 m)

  • Operating temperature: 32° to 122°F (0° to 50°C)

  • Operating humidity: 10% to 90% (non-condensing)

  • Operating altitude test: 40˚C (104°F) at 9843 ft (3000 m)
Reliability
  • Mean Time Between Failure (MTBF): 998,440 hrs at +25°C operating temperature
Physical Dimensions

  • 7.8 x 7.8 x 1.7 in. (200 x 200 x 44.45 mm)

  • Weight: 2.05 lb. (0.93 kg)
Security

  • Integrated Layer 7 firewall with mobile device policy management

  • Real-time WIDS/WIPS with alerting and automatic rogue AP containment with Air Marshal

  • Flexible guest access with device isolation

  • VLAN tagging (802.1q) and tunneling with IPsec VPN

  • PCI compliance reporting

  • WPA2-PSK, WPA2-Enterprise, WPA3 – Personal, WPA3 – Enterprise, WPA3 – Enhanced Open (OWE)

  • EAP Local Authentication – EAP-TTLS/PAP/ PEAP-GTC, EAP-TLS

  • AES encryption

  • Enterprise Mobility Management (EMM) & Mobile Device Management (MDM) integration

  • Cisco ISE integration for Guest access and BYOD Posturing
Quality of Service

  • Advanced Power Save (U-APSD)

  • WMM Access Categories with DSCP and 802.1p support

  • Layer 7 application traffic identification and shaping
Mobility

  • PMK, OKC, & 802.11r for fast Layer 2 roaming

  • Distributed or centralized layer 3 roaming
Analytics

  • Embedded location analytics reporting and device tracking

  • Global L7 traffic analytics reporting per network, per device, & per application
LED Indicators

  • One power/booting/firmware upgrade status
Regulatory

  • RoHS

  • For additional country-specific regulatory information, please contact Meraki sales
Warranty
  • Limited Lifetime hardware warranty
Ordering Information

  • CW9162I-MR: Catalyst CW9162I Cloud Managed 802.11ax Compatible AP

  • MA-PWR-30W-XX: Meraki AC Adapter for MR Series

  • MA-INJ-6: Meraki Multigigabit 802.3bt Power over Ethernet Injector (power cable separate SKU)

  • Cisco AIR-PWRINJ-6 802.3at

  • Cisco AIR-PWRINJ-7 802.3bt

  • Cisco AIR-PWRINJ-6 802.3at power cord – MA-PWR-CORD-XX (XX Country Code) should be ordered separately for the AC adapter and Ethernet injector

  • Mounting bracket: AIR-AP-BRACKET-1 and AIR-AP-BRACKET-2(bundled)

  • Meraki access point license required
