| Specifications | |
| Product | Workstations |
| Manufacture | Dell |
| Model | Precision T7820 – 42PT78D027 |
| Microprocessor | Intel® Xeon® Copper Processor 3104 |
| 8.25M, 1.70 GHz cache (6 cores / 6 threads) | |
| Chipset | Intel® C621 (Lewisburg) |
| Graphics card | Discrete VGA, Quadro P2000 5GB |
| Supports 2 PCI Express® x16 Gen 3 graphics cards – up to 600W with up to 2 x 300W dual graphics cards on single CPU | |
| Memory | 16Gb (2x8Gb) DDR4 DDR4 ECC Memory |
| Hard Drive | 2Tb |
| Supports up to 4 x 2.5 GB / 3.5 inch Hard Drive / SSD | |
| Network connections | Intel® i219 Gigabit Ethernet Controller with Intel Remote Wake UP, PXE and Jumbo Frame Support |
| Optional: Single port Intel® i210 10/100/1000 | |
| Gigabit network card PCIe (Gen 3 x1), Intel® | |
| PCIe dual port X550-T2 10GbE (Gen 3 x4) | |
| network card, Intel Dual Band Wireless AC 8265 | |
| (802.11ac) 2×2 + Bluetooth module, | |
| Optical drive | DVD + /- RW |
| Accessory | Key/mouse |
| The web of communication | Front |
| 2 – USB 3.1 Gen 1 Type A | |
| 2 – USB 3.1 Type | |
| 1 – Universal Audio Jack | |
| internal | |
| 1 – USB 2.0 type A | |
| Header 1 – 2 x 5 USB 2.0. | |
| (requires 3rd party splitter cable support | |
| 2 x USB 2.0 Type-A ports) | |
| 6 – SATA @ 6Gb/s plus 2 for optical | |
| Rear part | |
| 6 – USB 3.1 Gen 1 Type A | |
| 1 – serial | |
| 1 – RJ45 . Network | |
| 2 – PS2 | |
| 1 lineAudio Line out | |
| 1 Audio Line In / Microphone | |
| Expansion slot | Optional: Dell Precision SuperSpeed Drive |
| Duo (HH/HL, x8) and super-speed drive | |
| Quad (FH/FL, x16) with active cooling. | |
| Supports up to 2 and 4 M.2 PCIe NVMe SSDs respectively. | |
| Optional USB C card 3.1 (Gen 2) 10Gb/s | |
| Power capacity | 950W (input voltage 100VAC – 240VAC) –90% efficiency (80PLUS Gold Certified) |
| Externally accessible/removable/lockable | |
| Operating system | Ubuntu Linux 16.04 |
| Designs | stand up case |
| Size | Width: 6.95 (176.5mm) | Depth: 20.4 (518.2 mm) |
| Weight | 15.4 Kg |
