SPECIFICATIONS
DISPLAY BACKGROUND
-
- Screen size
- 55″
- Screen technology
- IPS
-
- Original resolution
- 3,840 × 2,160 (UHD)
- Brightness (Typical)
- 400 nits
-
- Dynamic Contrast
- 1,000,000:1
- Colors
- DCI 80%
-
- Viewing Angle (Horizontal x Vertical)
- 178 x 178
- Color depth
- Advanced 10bit, 1.07 billion colors
-
- Response time
- 8 ms (G to G)
- Surface treatment
- 3%
-
- Hours of Operation (Hours/Days)
- 16/7
- Vertical / Horizontal
- Yes / Yes
-
- Scan frequency
- 60 Hz
CONNECT
-
- Input
- HDMI (3, HDCP 2.2 / 1.4), USB 2.0 Type A (2)
- Output
- Sound
-
- External control
- RS232C In / Out (4-pin Telephone Jack), RJ45 (LAN) In
MECHANICAL SPECIFICATIONS
-
- Border color
- Smoke blue
- Border width
- Off: 6.9/6.9/6.9/18.4
On: 12.8/12.8/12.8/19.9
-
- Mass
- 14.0 kg
- Screen Size (W x H x D)
- 1,235 x 715 x 57.5 mm
-
- Carton Size (Width x Height x Thickness)
- 1,360 x 810 x 162mm (Dimensions outside the box)
- Installation price
- Are not
-
- VESA™ standard mounting bracket
- 300 × 300 mm
ENVIRONMENTAL CONDITIONS
-
- Operating temperature
- 0 °C to 40 °C (Scene vertically: 0 °C to 35 °C)
- Operating humidity
- 10% to 80%
SOURCE
-
- Electricity supply
- AC 100-240V~, 50/60Hz
- Source Type
- Built-in source
POWER CONSUMPTION
-
- Normal/Max
- 105 W / 160 W
- BTU (British Thermal Unit)
- 358 BTU/hr (Normal), 546 BTU/hr (Max)
CERTIFICATE
-
- Safety
- CB, NRTL
- YOU C
- FCC Class “A” / CE
-
- ErP
- UPDATING
COMPATIBILITY WITH US SOFTWARE
-
- SuperSign CMS
- Have
- SuperSign Control/Control+
- Have
-
- SuperSign WB
- Have
- SuperSign Media Editor
- Have
-
- LG ConnectedCare
- Have
- Promota
- Have
SOUND
-
- Loudspeaker
- Have
ACCESSORY
-
- Basic
- Remote control (2ea batteries included), Power cord, Regulatory book, D-Sub9 phone adapter, Cable holder
