SPECIFICATIONS
WALLET SHEET
-
- Screen size
- 32″
- Screen technology
- IPS
-
- Original resolution
- 1,920 x 1,080 (FHD)
- Brightness (nits)
- 500
-
- Contrast ratio
- 1,000:1
- Colors
- NTSC 72%
-
- Viewing Angle (Horizontal × Vertical)
- 178 × 178
- Color depth
- 8bit, 16.7 million colors
-
- Response time
- 9ms (G to G)
- Surface Treatment (Matte Coating)
- Low blind coverage (3%)
-
- Hours of Operation (Hours/Days)
- 24/7
- Vertical / Horizontal
- Yes / Yes
CONNECT
-
- Input
- Digital (HDMI(2), HDCP 1.4), RS232C IN, RJ45(LAN), IR IN, USB2.0 Type A(1)
- Way out
- Audio Out, USB2.0 Type B (1)
MECHANICAL SPECIFICATIONS
-
- Border color
- Mother u ‘en
- Border width
- 11.3/11.3/11.3/13.2 mm
-
- Volume (Home screen)
- 5.6Kg
- Screen Size (Width × Height × Depth)
- 723.0 x 419.4 x 39.1 mm
-
- VESATM . standard mounting interface
- 200 x 200
MAIN FEATURES(HARDWARE)
-
- Internal memory
- 8GB (5GB System + 2.48GB Available)
- Temperature sensor
- HAVE
MAIN FEATURES(SOFTWARE)
-
- WebOS version
- webOS 6.0
- Embedded CMS
- Local Content Scheduling, Group Management
-
- USB Plug & Play
- HAVE
- Failover
- HAVE
-
- Background images
- Boot logo image, Image no signal
- Video Cards
- HAVE
-
- Play via URL
- HAVE
- Rotate the screen
- HAVE
-
- Play without interruption
- HAVE
- Duplicate installation data
- HAVE
-
- SNMP
- HAVE
- ISM method
- HAVE
-
- Send a status message
- HAVE
- Control Management
- HAVE
-
- 3rd party compatibility
- Crestron inside
- WOMEN»’WOMEN
- Smart Power Saving, PM Mode, Wake on LAN, Network Ready
-
- HDMI-CEC
- HAVE
- SI server settings
- HAVE
-
- webRTC
- HAVE
- Pro:Idiom
- HAVE
ENVIRONMENTAL CONDITIONS
-
- Operating temperature
- 0°C to 40°C
- Operating humidity
- 10% to 80%
WOMEN»’WOMEN
-
- Electricity supply
- AC 100-240V~, 50/60Hz
- Source Type
- Built-in source
POWER CONSUMPTION
-
- Particular
- 55 W
- Dou»’i Ä’a
- 65 W
-
- BTU (British Thermal Unit)
- 188 BTU/hour (Normal), 222 BTU/hour (Max)
CERTIFICATE
-
- Safety
- CB / NRTL
- YOU C
- FCC Group “A” / CE / KC
-
- ErP
- HAVE
COMPATIBILITY WITH US SOFTWARE
-
- SuperSign CMS
- HAVE
- SuperSign Control/Control+
- HAVE
-
- Signage 365 Care
- HAVE
ACCESSORY
-
- Basic
- 1.55m Power Cord, 1.8m USB Cable (Type A-Type B), User Manual, QSG, Remote Controller (2ea battery included), RS232C Port, IR Receiver
SENSOR
-
- Touch object size
- 6mm
- Response Time (Based on ‘Paint’ app on Windows 10 PC)
- 90ms
-
- Accuracy
- 3.5mm±0.5mm
- The web of communication
- USB 2.0
-
- Operating system support
- Windows 10
- Multitouch
- Up to 10 points
