SPECIFICATIONS
DISPLAY BACKGROUND
  • Screen size
    21.5”
    Screen technology
    IPS
  • Screen ratio
    16:09
    Original resolution
    1,920 x 1,080 (FHD)
  • Refresh rate
    60 Hz
    Brightness (Typical, cd/m²)
    250
  • Contrast ratio
    1,000 : 1
    Viewing Angle (Horizontal x Vertical)
    178 x 178
  • Response time
    14ms (G to G)
    Surface Treatment (Dust)
    25%
  • Lifespan (Min.)
    30,000 Hrs
    Hours of Operation (Hours/Days)
    16/7
  • Vertical / Horizontal
    Yes / Yes
CONNECT
  • Input
    HDMI (2, HDCP2.2), USB 2.0 Type A, Audio In
    External control
    RS232C In (Phone-jack), RJ45 (LAN) In, IR In
MECHANICAL SPECIFICATIONS
  • Border color
    Black
    Border width
    16.3 mm (Even contour)
  • Mass
    3.34 kg
    Packing volume
    4.74 kg
  • Screen Size (W x H x D)
    510.3 x 302.1 x 53.8 mm
    Carton Size (Width x Height x Thickness)
    565.0 x 357.0 x 103.0 mm
  • Installation price
    No
    VESA™ standard mounting bracket
    100 x 100 mm
FEATURE
  • main feature
    8GB Internal Storage, Built-in Wi-Fi, Temperature Sensor, Local Key Operation, Embedded CMS (Local Content Scheduling, Team Manager), USB Plug & Play, Failure, Wallpaper (Fig. boot image, Image without signal), PIP , PBP (2), Screen Sharing, Play via URL, Data Copy Settings, SNMP, ISM (Imaging Smudge Reduction), Control Manager , Crestron Connected® (Network Based Control), Smart Energy Saver, PM Mode, Wake on LAN, Beacon, HDMI-CEC (Compatibility may vary by device), Install SI server, webRTC, Pro: Idiom
ENVIRONMENTAL CONDITIONS
  • Operating temperature
    0°C to 40°C
    Operating humidity
    10% to 80%
SOURCE
  • Electricity supply
    AC 100 – 240 V ~, 50 / 60 Hz
    Source Type
    Built-in source
  • Power Consumption (Typical / Max)
    30 W / 33 W
    Power Consumption (Smart Power Saving)
    15 W ± 5 %
SOUND
  • Loudspeaker
    Yes (1 W x 2 ea)
CERTIFICATE
  • Safety
    CB / NRTL
    YOU C
    FCC Class “A” / CE
  • ErP
    Yes (EU Only)
    ePEAT (US Only)
    No
COMPATIBLE OPS
  • Compatible with OPS . type
    No
    Built-in OPS source
    No
COMPATIBILITY WITH US SOFTWARE
  • Content Management Software
    SuperSign CMS
    Control and monitoring software
    SuperSign Control/Control+
  • Signage365Care
    Yes (The “Signage365Care” service offered varies from country to country, so,)
ACCESSORY
  • Basic
    Remote controller, Power cord, QSG, HDMI cable, Phone to RS232C Guide, External IR Receiver, IR Sheet
Manufacturer
