Thông số kỹ thuật: Firewall FortiGate FG-200D
GE RJ45 WAN Interfaces: 2
GE RJ45 LAN Interfaces: 16
GE RJ45 PoE LAN Interfaces
GE SFP DMZ Interfaces: 2
USB (Client / Server): 1 / 1
Console (RJ45): 1
Local Storage: 64 GB
Included Transceivers
System Performance and Capacity
Firewall Throughput (1518 / 512 / 64 byte, UDP): 3 / 3 / 3 Gbps
Firewall Latency (64 byte, UDP): 2 μs
Firewall Throughput (Packet per Second): 4.5 Mpps
Concurrent Sessions (TCP): 2 Million
New Sessions/Sec (TCP): 77,000
Firewall Policies: 10,000
IPsec VPN Throughput (512 byte): 1.3 Gbps
Gateway-to-Gateway IPsec VPN Tunnels: 2000
Client-to-Gateway IPsec VPN Tunnels: 10,000
SSL-VPN Throughput: 400 Mbps
Concurrent SSL-VPN Users: 300
SSL Inspection Throughput (IPS, HTTP): 340 Mbps
Application Control Throughput (HTTP 64K): 1.5 Gbps
CAPWAP Throughput (1444 byte, UDP): 1.8 Gbps
Virtual Domains (Default / Maximum): 10 / 10
Maximum Number of Switches Supported: 24
Maximum Number of FortiAPs (Total / Tunnel Mode): 128 / 64
Maximum Number of FortiTokens: 1,000
Maximum Number of Registered FortiClients: 600
High Availability Configurations
Active / Active, Active / Passive, Clustering
System Performance — Optimal Traffic Mix
IPS Throughput: 1.7 Gbps
System Performance — Enterprise Traffic Mix
IPS Throughput: 420 Mbps
NGFW Throughput: 330 Mbps
Threat Protection Throughput: 310 Mbps
Dimensions and Power
Height x Width x Length (inches): 1.75 x 17.01 x 11.73
Height x Width x Length (mm): 44 x 432 x 298
Weight: 10.5 lbs (4.8 kg)
Form Factor: 1 RU
AC Power Supply: 100–240V AC, 60–50 Hz
Maximum Current: 110 V / 3 A, 220 V / 1.5 A
Power Consumption (Average / Maximum): 49 / 83 W
Heat Dissipation: 374.9 BTU/h
Total Available PoE Power Budget
Operating Temperature: 32–104°F (0–40°C)
Storage Temperature: -31–158°F (-35–70°C)
Humidity: 10–90% non-condensing
Operating Altitude
Up to 7,400 ft (2,250 m)
Compliance: FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB
Certifications
ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6
