Cambium HUB 360r cnVision Hub

The Cambium cnVission HUB 360r is a 360-degree Azimuth, Omnidirectional (Azimuth) Antenna Hub, used to connect multiple cameras in any direction. HUB 360r supports ONVIF compatible with many famous cameras on the market such as Panasonic, Hikvision, Mobotix… and also integrates VMS to effectively manage and monitor wireless networks.

Categories: , Tags: , , , , , , ,

Thông số kỹ thuật HUB 360r

Specifications
HUB 360r Datasheet
Primary Use An omnidirectional Hub to connect many cameras in any direction
Antenna Type Omnidirectional
Antenna Gain 9 dBi
Antenna Beamwidth
Azimuth 360º
Elevation 10º
Power Consumption 13 Watts
Input voltage 48 V PoE (802.3at compliant)
Dimensions 30 x 20.4 x 6.5 cm (11.8 x 8 x 2.55 in)
Weight 0.9kg (2.0 lbs) without brackets
Environmental IP67
Temperature -30°C to 60°C (-22°F to 140°F)
Wind Survival 200 km/h (124 mph)
Certifications FCCIDZ8H89FT0051, IC – 109W-005
CE – EN 301 893 V2.1.1 (5.4 GHz),
EN 302 502 V2.1.1 (5.8 GHz)
