Ubiquiti LiteBeam LBE-5AC-23 – Technical Specifications
Physical / Electrical / Environmental
Dimensions – 362 x 273 x 203 mm (No Mount) – (14.25 x 10.75 x 7.99″)
Weight (No Mount) 907 g (2.00 lbs)
Wind Survivability 200 km/h (125 mph)
Wind Loading 283 N @ 200 km/h (63.6 lbf @ 125 mph)
Mounting Kit Pole Mounting Kit (Included)
Max. Power Consumption 7W
Power Supply 24V, 0.3A Gigabit PoE Adapter (Included)
Power Method Passive PoE (Pairs 4, 5+; 7, 8 Return)
Operating Temperature -40 to 70° C (-40 to 158° F)
Operating Humidity 5 to 95% Noncondensing
Shock and Vibration ETSI300-019-1.4
– ETSI Specification EN 302 326 DN2
– ESD/EMP Protection ± 24 KV Contact / Air
System Information
– Processor Specs MIPS 74K
– Memory 64 MB
– Networking Interface (1) 10/100/1000 Ethernet Port
Regulatory / Compliance Information
– Wireless Approvals FCC, IC, CE
– RoHS Compliance Yes
