Available Operating Systems
Windows 10 Pro 64 – HP recommends Windows 10 Pro for business
Windows 10 Pro 64 (National Academic only)
Windows 10 Home 64
Windows 10 Home Single Language 64
FreeDOS
Processor family
10th Generation Intel® Core™ i3 processor; 10th Generation Intel® Core™ i5 processor; 10th Generation Intel® Core™ i7 processor; Intel® Celeron® processor;
Intel® Pentium® processor
Available Processors
Intel® Core™ i7-10700T with Intel® UHD Graphics 630 (2.0 GHz base frequency, up to 4.4 GHz with Intel® Turbo Boost Technology, 16 MB L3 cache, 8 cores)
Intel® Core™ i5-10600T with Intel® UHD Graphics 630 (2.4 GHz base frequency, up to 4.0 GHz with Intel® Turbo Boost Technology, 12 MB L3 cache, 6 cores)
Intel® Core™ i5-10500T with Intel® UHD Graphics 630 (2.3 GHz base frequency, up to 3.8 GHz with Intel® Turbo Boost Technology, 12 MB L3 cache, 6 cores)
Intel® Core™ i3-10300T with Intel® UHD Graphics 630 (3.0 GHz base frequency, up to 3.9 GHz with Intel® Turbo Boost Technology, 8 MB L3 cache, 4 cores)
Intel® Core™ i3-10100T with Intel® UHD Graphics 630 (3.0 GHz base frequency, up to 3.8 GHz with Intel® Turbo Boost Technology, 6 MB L3 cache, 4 cores)
Intel® Pentium® Gold G6500T with Intel® UHD Graphics 630 (3.5 GHz base frequency, 4 MB L3 cache, 2 cores)
Intel® Pentium® Gold G6400T with Intel® UHD Graphics 610 (3.4 GHz base frequency, 4 MB L3 cache, 2 cores)
Intel® Celeron® G5900T with Intel® UHD Graphics 610 (3.2 GHz base frequency, 2 MB L3 cache, 2 cores)
Chipset Intel® Q470
Form factor Mini
Maximum memory
64 GB DDR4-2666 SDRAM; 64 GB DDR4-3200 SDRAM
Transfer rates up to 2666 MT/s for Celeron®, Pentium®, Intel® Core™ i3, and Intel® Core™ i5 processors. Transfer rates up to 2933 MT/s for Intel® Core™ i7
processors
Memory slots 2 SODIMM
Internal storage
500 GB up to 2 TB SATA HDD
500 GB SATA SED Opal 2 HDD
500 GB SATA SED FIPS HDD
128 GB up to 2 TB PCIe® NVMe™ TLC M.2 SSD
256 GB up to 512 GB PCIe® NVMe™ SED Opal 2 TLC M.2 SSD
256 GB up to 512 GB Intel® Optane™ Memory H10 with Solid State Storage
Storage acceleration 16 GB NVMe™ Intel® Optane™ Memory for storage acceleration
Available Graphics
Integrated: Intel® UHD Graphics 630; Intel® UHD Graphics 610
(Integrated graphics will depend on processor.)
Audio Realtek ALC3205 codec, internal speaker, combo microphone/headphone jack
Expansion slots 1 M.2 2230; 1 M.2 2280 (1 M.2 slot for WLAN and 1 M.2 2280 slot for storage.)
Ports and Connectors
Front: 1 headphone/microphone combo; 1 SuperSpeed USB Type-C® 10Gbps signaling rate; 1 SuperSpeed USB Type-A 10Gbps signaling rate; 1 SuperSpeed
USB Type-A 5Gbps signaling rate (charging)
Rear: 1 RJ-45; 1 DisplayPort™ 1.4; 2 SuperSpeed USB Type-A 5Gbps signaling rate; 1 HDMI 1.4b; 2 USB Type-A 480Mbps signaling rate
Optional Ports
Flex IO port 1 – choose one of the following options: DisplayPort™ 1.4, HDMI 2.0, VGA, serial, SuperSpeed USB Type-C® 10Gbps signaling rate (100W Power
Delivery, alternate mode DisplayPort™); Flex IO port 2 – choose one of the following options: 2 USB 2.0 Type-A 480Mbps signaling rate or serial
Available Keyboards
HP Wireless Business Slim Keyboard and Mouse Combo; HP USB wired keyboard; HP Wired Desktop 320K Keyboard; HP USB PS2 Washable Keyboard; HP USB
Business Slim Smart Card (CCID) Keyboard
Available Pointing Devices HP USB 1000 dpi Laser Mouse; HP USB and PS/2 Washable Mouse; HP Wired Desktop 320M Mouse
LAN Network Interface Intel® I219LM GbE
WLAN Intel® Wi-Fi 6 AX201 (2×2) Wi-Fi® and Bluetooth® M.2 combo card, non-vPro™
Drive Bays One 2.5″
Environmental Operating temperature: 10 to 35°C; Operating humidity: 10 to 90% RH
Software HP Noise Cancellation Software; HP Support Assistant; Buy Office (sold separately); HP JumpStarts; HP Desktop Support Utilities
Security management
Power-on password (via BIOS); SATA port disablement (via BIOS); Setup password (via BIOS); Support for chassis padlocks and cable lock devices; USB
enable/disable (via BIOS); Serial enable/disable (via BIOS); HP Secure Erase; HP Sure Click; HP Sure Sense; HP BIOSphere Gen5; HP DriveLock and Automatic
DriveLock; Trusted Platform Module TPM 2.0 Embedded Security Chip shipped with Windows 10. (Common Criteria EAL4+ Certified); HP Client Security
Manager Gen6
Management features
HP BIOS Config Utility (download); HP Client Catalog (download); HP Driver Packs (download); HP System Software Manager (download); HP Cloud Recovery; HP
Management Integration Kit for Microsoft System Center Configuration Management Gen 4; HP Image Assistant Gen 5
Power 65 W external power adapter, up to 89% efficiency
Dimensions 6.97 x 6.89 x 1.34 in; 17.7 x 17.5 x 3.4 cm
Weight 2.75 lb; 1.25 kg (Exact weight depends on configuration.)
Energy efficiency compliance ENERGY STAR® certified; EPEAT® 2019 registered where applicable
Environmental specifications Low halogen
Warranty
3 year (3-3-3) limited warranty and service offering includes 3 years of parts, labor and on-site repair. Includes free 24/7 telephone support. Terms and
conditions vary by country. Certain restrictions and exclusions apply
