Thông số kỹ thuật của Cisco Meraki MR86
| Radios | – 2.4 GHz 802.11b/g/n/ax client access radio – 5 GHz 802.11a/n/ac/ax client access radio – 2.4 GHz & 5 GHz dual-band WIDS/WIPS, spectrum analysis, & location analytics radio – 2.4 GHz Bluetooth Low Energy (BLE) radio with Beacon and scanning support – Concurrent operations of all four radios |
| Supported frequency bands (country-specific restrictions apply) | – 2.412-2.484 GHz – 5.150-5.250 GHz (UNII-1) – 5.250-5.350 GHZ (UNII-2) – 5.470-5.600, 5.660-5.725 GHz (UNII-2e) – 5.725 -5.825 GHz (UNII-3) |
| 802.11ax, 802.11ac Wave 2, and 802.11n Capabilities | – UL/DL OFDMA, TWT support, BSS coloring – 4 x 4 multiple input, multiple output (MIMO) with four spatial streams – UL/DL SU-MIMO and MU-MIMO support – Maximal ratio combining (MRC) & beamforming – 20 and 40 MHz channels (802.11n); 20, 40, and 80 MHz channels (802.11ac Wave 2); 20, 40 and 80 MHz channels (802.11ax) – Up to 1024 QAM on both 2.4 GHz and 5 GHz bands – Packet aggregation |
| Power | – Power over Ethernet: 42.5 – 57 V (802.3at compatible) – Power consumption: 18 W max – Power over Ethernet injector sold separately |
| Mounting | – Mounts to walls and vertical poles. – Mounting hardware included |
| Environment | – Operating temperature: -40 °F to 131 °F (-40 °C to 55 °C) – Humidity: 5 to 95% non-condensing – IP67 environmental rating |
| Physical Dimensions | – 11.81” x 6.02” x 2.16” (30.0 cm X 15.3 cm X 5.5 cm), not including cable gland, mounts or antennas – Weight: 52.91 oz (1.5 kg) |
| Interfaces | 1x 100/1000/2.5G BASE-T Ethernet (RJ45) |
| Security | – Integrated Layer 7 firewall with mobile device policy management – Real-time WIDS/WIPS with alerting and automatic rogue AP containment with Air Marshal – Flexible guest access with device isolation – VLAN tagging (802.1q) and tunneling with IPsec VPN – PCI compliance reporting – WEP, WPA, WPA2-PSK, WPA2-Enterprise with 802.1X, WPA3 – Personal, WPA3 – Enterprise, WPA3 – – Enhanced Open (OWE) – EAP-TLS, EAP-TTLS, EAP-MSCHAPv2, EAP-SIM – TKIP and AES encryption – Enterprise Mobility Management (EMM) & Mobile Device Management (MDM) integration – Cisco ISE integration for Guest access and BYOD Posturing |
